Specifications below for more details on 7075 Aluminum Alloy.
The following table shows the chemical composition of aluminum alloy 7075.
The aluminum alloy properties 7075 physical are tabulated below.
|Tensile strength||220 MPa||31909 psi|
|Yield strength||95 MPa||13779 psi|
|Shear strength||150 MPa||21756 psi|
|Fatigue strength||160 MPa||23206 psi|
|Elastic modulus||70-80 GPa||10153-11603 ksi|
|Elongation at break||17%||17%|
The thermal properties of aluminum alloy 7075 is given in the table below.
|Thermal expansion||23.2 (10-6/ºC)||20-100||–|
|Thermal conductivity||130 W/mK||25||T6|
|ASTM B209||ASTM B468||QQ A-200/15|
|AMS 4045||ASTM B210||DMS 2233||QQ A-225/9|
|AMS 4049||ASTM B211||MIL A-12545||QQ A-250/13|
|AMS 4131||ASTM B221||MIL A-22771||QQ A-250/24|
|AMS 4147||ASTM B241||MIL F-18280||QQ A-367|
|AMS 4154||ASTM B247||MIL F-5509||QQ A-430|
|AMS 4323||ASTM B316||QQ A-200/11||QQ WW-T-700/7|
Fabrication and heat treatment
Aluminum alloy 7075 can be machined in the annealed condition. Lubricating oils are used to perform the machining operations.
See more ... What Is Aluminum Alloy 101
Aluminum alloy 7075 can be formed in the annealed condition. It can be kept warm 94 to 122 ° C (200 to 250 ° F) if any difficulties are encountered.
Aluminum alloy 7075 can be welded by means of welding. Gas welding method is not preferred for this alloy. Arc welding method should also be avoided because it leads to the degradation of corrosion-resistant properties of the alloy.
Aluminum alloy 7075 is annealed at (900 ° F) for 2 hours followed by water quenching and heat treatment of hard rain.
Aluminum alloy 7075 is forged at 372-483 ° C (700-900 ° F).
Aluminum 7075 alloy can be hot 7075 working at 122 ° C (250 ° F)
7075 7075 aluminum alloy can be cold worked using conventional methods and soft annealed condition.
Aluminum alloy 7075 is annealed at 413 ° C (775 ° F) for 3 hours followed by cooling controlled at 10-260 ° C (50 to 500 ° F) per hour, and cooled in air.
Aluminum alloy 7075 can be 122 years old in ° C (250 ° F) for 24 hours to get T 6 temper. 73 T calm can be heated at 108 ° C (225 ° F) for 8 hours and 163 ° C (325 ° F) for 24 hours followed by air cooling.
Aluminum alloy 7075can be hardened by heat treatment of precipitation.
Aluminum alloy 7075 is used primarily in the manufacture of aircraft and aerospace applications.
Alloy code: A7075
As high-strength alloys in all kinds of aluminum alloy. Plated alloy plates (7072) are plated with a thin layer on the surface to improve corrosion resistance.
Material plane, ski boots, ...
Chemical Composition (%): Si: max 0.4, Fe: 12:50 max, Cu: 1.2 ~ 2.0, Mn: 12:30 max, Mg: 2.1 ~ 2.9, Cr: 12:18 ~ 12:28, Zn: 5.1 ~ 6.1, Zr + Ti : 12:25 max, Ti: 12:20 max, Al: left (Remainder)
